Attributes:
| CORE DIM (H x W): 22 5/8 X 23 7/8 |
| OVERALL (H x W): 29 1/8 X 26 1/4 |
| HOSE LOCATIONS: IN: CENTER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 3/4 - OUT: 1 3/4 |
| FILL NECK: YES |
| TRANS COOLER: 1/2-20 STRAIGHT THREAD, INVERTED FLARE |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 4 ROW |
| CORE THICKNESS: 2 3/4 |
| TANK WIDTH: 3 1/8 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1955 - 1959 GMC Truck |
