Attributes:
| CORE DIM (H x W): 13 3/4 X 23 1/4 |
| OVERALL (H x W): 19 3/4 X 27 1/4 |
| HOSE LOCATIONS: IN: DRIVER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 1/4 - OUT: 1 1/4 |
| FILL NECK: YES |
| TRANS COOLER: M14-1.5 |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 4 ROW |
| CORE THICKNESS: 2 3/4 |
| TANK WIDTH: 3 1/8 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1970 - 1973 Datsun 240Z | 2.4 L6, 2.6L L6, 2.8L L6, 3.1L L6 | |
| 1974 - 1975 Datsun 260Z | 2.4 L6, 2.6L L6, 2.8L L6, 3.1L L6 |
