Available Packages:
CCHVB
CCHVB
Attributes:
| CORE DIM (H x W): 24 1/4 X 26 3/4 |
| OVERALL (H x W): 30 5/8 X 28 3/8 |
| HOSE LOCATIONS: IN: DRIVER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 3/4 - OUT: 2 |
| FILL NECK: YES |
| MOUNTING TYPE: OEM |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/2 |
| TANK WIDTH: 3 1/8 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1992 - 2001 AM General Hummer | Fits a military style Humvee from 1984 to present, 5.7L 350ci V8, 6.2L 379ci V8, 6.5L 395ci V8 | |
| 2002 - 2004 Hummer H1 | Fits a military style Humvee from 1984 to present, 6.5L 395ci V8 | |
| 2006 Hummer H1 Alpha | Fits a military style Humvee from 1984 to present, 6.6L 400ci V8 |
