Available Packages:
CC9126
CC9126
Attributes:
| CORE DIM (H x W): 23 1/2 X 26 7/8 |
| OVERALL (H x W): 30 7/8 X 27 1/2 |
| HOSE LOCATIONS: IN: PASSENGER - OUT: DRIVER |
| HOSE FITTINGS: IN: 1 3/8 - OUT: 1 3/8 |
| FILL NECK: YES |
| TRANS COOLER: 1/4-18NPT |
| MOUNTING TYPE: PIN |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 |
| TANK WIDTH: 2 5/8 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 2004 - 2010 Nissan Titan | 5.6L 342ci V8 |
