Available Packages:
CC829DP CC829DP + 2 x CCFK10 CC829DP + 2 x CCFK12 CC829DP + FS829-2x12 + 2 x CCFK12
CC829DP CC829DP + 2 x CCFK10 CC829DP + 2 x CCFK12 CC829DP + FS829-2x12 + 2 x CCFK12
Attributes:
| CORE DIM (H x W): 14 1/2 X 23 5/8 |
| OVERALL (H x W): 16 5/8 X 29 3/4 |
| HOSE LOCATIONS: IN: PASSENGER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 16ORB(FEMALE) - OUT: 16ORB(FEMALE) |
| FILL NECK: YES |
| MOUNTING TYPE: SADDLE |
| FLOW DIRECTION: CROSS FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/4 |
| TANK WIDTH: 2 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1984 - 1990 Chevrolet Corvette | Small Block LS Swap | |
| 1984 - 1990 Chevrolet S10 | Small Block LS Swap |
