Attributes:
| CORE DIM (H x W): 14 1/2 X 23 5/8 |
| OVERALL (H x W): 16 3/8 X 29 1/8 |
| HOSE LOCATIONS: IN: DRIVER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 1/4 - OUT: 1 3/8 |
| FILL NECK: YES |
| TRANS COOLER: 1/2-20 STRAIGHT THREAD, INVERTED FLARE |
| MOUNTING TYPE: SADDLE |
| FLOW DIRECTION: CROSS FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/4 |
| TANK WIDTH: 2 1/2 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1984 - 1990 Chevrolet Corvette | Small Block V8 | |
| 1984 - 1990 Chevrolet S10 | V8 Conversion |
