Attributes:
| CORE DIM (H x W): 18 7/8 X 24 7/8 |
| OVERALL (H x W): 21 1/8 X 9 5/8 |
| HOSE LOCATIONS: IN: PASSENGER - OUT: DRIVER |
| HOSE FITTINGS: IN: 1 3/4 - OUT: 1 3/4 |
| TRANS COOLER: 1/4-18 NPT |
| MOUNTING TYPE: OEM |
| FLOW DIRECTION: CROSS FLOW |
| CORE ROWS: 3 |
| CORE THICKNESS: 2 1/4 |
| TANK WIDTH: 2 1/2 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1966 - 1967 Lincoln Continental | 7.6L 426ci V8 |
