Attributes:
| CORE DIM (H x W): 18 1/2 X 18 3/8 |
| OVERALL (H x W): 25 3/8 X 23 1/8 |
| HOSE LOCATIONS: IN: PASSENGER - OUT: DRIVER |
| HOSE FITTINGS: IN: 1 1/2 - OUT: 2 |
| FILL NECK: YES |
| TRANS COOLER: 1/8-27NPT |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/2 |
| TANK WIDTH: 0 1/4 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1955 - 1956 Mercury Custom | 4.8L 292 V8, 5.1L 312ci V8 | |
| 1956 Mercury Medalist | 5.1L 312ci V8 | |
| 1955 - 1956 Mercury Montclair | 4.8L 292 V8, 5.1L 312ci V8 | |
| 1955 - 1956 Mercury Monterey | 4.8L 292 V8, 5.1L 312ci V8 |
