Attributes:
| CORE DIM (H x W): 22 X 22 |
| OVERALL (H x W): 27 7/8 X 24 |
| HOSE LOCATIONS: IN: OFF-SET PASSENGER - OUT: DRIVER |
| HOSE FITTINGS: IN: 1 1/2 - OUT: 1 3/4 |
| FILL NECK: YES |
| TRANS COOLER: 1/2-20 STRAIGHT THREAD, INVERTED FLARE |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/2 |
| TANK WIDTH: 0 1/8 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1950 Oldsmobile 88 | 5.0L 303ci V8 | |
| 1949 Oldsmobile Series 78 | 5.0L 303ci V8 | |
| 1949 Oldsmobile Series 88 | 5.0L 303ci V8 | |
| 1949 Oldsmobile Series 98 | 5.0L 303ci V8 |
