Attributes:
| CORE DIM (H x W): 22 X 16 3/4 |
| OVERALL (H x W): 27 7/8 X 20 1/8 |
| HOSE LOCATIONS: IN: CENTER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 1/4 - OUT: 1 1/2 |
| FILL NECK: YES |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 |
| TANK WIDTH: 0 1/4 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1941 Chevrolet Fleetline | 3.5L 217ci L6 | |
| 1941 Chevrolet Fleetmaster | 3.5L 217ci L6 | |
| 1941 Chevrolet Master 85 | 3.5L 217ci L6 | |
| 1940 - 1941 Chevrolet Special Deluxe | 3.5L 217ci L6 |
