Verify hose configuration and core size for your application before purchasing.
Attributes:
| CORE DIM (H x W): 16 X 24 1/4 |
| OVERALL (H x W): 21 3/4 X 25 1/4 |
| HOSE LOCATIONS: IN: PASSENGER - OUT: DRIVER |
| HOSE FITTINGS: IN: 1 1/2 - OUT: 1 3/4 |
| FILL NECK: YES |
| TRANS COOLER: 1/8-27NPT |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/4 |
| TANK WIDTH: 2 1/2 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1967 - 1969 Ford Fairlane | 6.4L 390ci V8, 7.0L 429ci V8 | |
| 1967 - 1970 Ford Mustang | 6.4L 390ci V8, 7.0L 428ci V8, 7.0L 429ci V8 | |
| 1967 - 1969 Ford Ranchero | 6.4L 390ci V8, 7.0L 429ci V8 | |
| 1968 - 1969 Ford Torino | 7.0L 428ci V8 | |
| 1968 - 1970 Mercury Cougar XR7 | 6.4L 390ci V8, 7.0L 428ci V8, 7.0L 429ci V8 |
