Attributes:
| CORE DIM (H x W): 17 X 23 |
| OVERALL (H x W): 19 1/4 X 30 1/4 |
| HOSE LOCATIONS: IN: DRIVER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 1/2 - OUT: 1 3/4 |
| FILL NECK: YES |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: CROSS FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/2 |
| TANK WIDTH: 2 3/4 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1967 - 1969 Chevrolet Camaro | 5.7L 350ci V8 | Designed for manual transmissions or with the use of an external transmission cooler |
| 1967 - 1969 Pontiac Firebird Trans Am | 5.2 V8, 5.7L 350ci V8 | Designed for manual transmissions or with the use of an external transmission cooler |
