Attributes:
| CORE DIM (H x W): 17 1/2 X 26 |
| OVERALL (H x W): 23 1/4 X 29 1/2 |
| HOSE LOCATIONS: IN: PASSENGER - OUT: DRIVER |
| HOSE FITTINGS: IN: 1 1/2 - OUT: 1 3/4 |
| FILL NECK: YES |
| TRANS COOLER: 1/8-27NPT |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 3 ROW |
| CORE THICKNESS: 2 1/4 |
| TANK WIDTH: 2 3/4 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1966 - 1969 Chrysler 300 | 6.3L 383ci V8, 7.2L 440ci V8 | |
| 1966 - 1969 Chrysler New Yorker | 7.2L 440ci V8 | |
| 1966 - 1969 Chrysler Newport | 6.3L 383ci V8, 7.2L 440ci V8 | |
| 1966 - 1969 Chrysler Town & Country | 6.3L 383ci V8, 7.2L 440ci V8 | |
| 1966 - 1969 Dodge Polara | 6.3L 383ci V8, 7.2L 440ci V8 | |
| 1966 - 1969 Plymouth Fury | 5.9L 361ci V8, 6.3L 383ci V8, 7.2L 440ci V8 |
