Attributes:
| CORE DIM (H x W): 19 3/8 X 21 3/4 |
| OVERALL (H x W): 26 3/4 X 26 1/2 |
| HOSE LOCATIONS: IN: CENTER - OUT: PASSENGER |
| HOSE FITTINGS: IN: 1 1/2 - OUT: 1 3/4 |
| FILL NECK: YES |
| TRANS COOLER: 1/2-20 STRAIGHT THREAD, INVERTED FLARE |
| MOUNTING TYPE: BRACKET |
| FLOW DIRECTION: DOWN FLOW |
| CORE ROWS: 2 ROW WITH 1" TUBES |
| CORE THICKNESS: 2 1/4 |
Applications:
| Name | Engine | Notes |
|---|---|---|
| 1959 Chevrolet 3B | 3.8L 235ci L6, 4.6L 283ci V8 | |
| 1959 Chevrolet 3C | 3.8L 235ci L6, 4.6L 283ci V8 | |
| 1959 Chevrolet 3D | 3.8L 235ci L6, 4.6L 283ci V8 | |
| 1959 Chevrolet 3E | 3.8L 235ci L6, 4.6L 283ci V8 | |
| 1959 Chevrolet 3F | 3.8L 235ci L6, 4.6L 283ci V8 | |
| 1959 Chevrolet 3G | 3.8L 235ci L6, 4.6L 283ci V8 | |
| 1955 - 1959 Chevrolet Suburban | ||
| 1955 - 1959 Chevrolet Truck | 3.8L 235ci L6, 4.3L 261ci L6, 4.3L 265ci V8, 4.6L 283ci V8, 5.3L 322ci V8, 5.3L 324ci V8 or a 5.7L 348ci V8 |
